VSCode extension inside nx workspace

vscode nx angular | François Guezengar | 15 Minuten

Building a good UX with VSCode extension can be difficult and might require to use webview. Here we see how nx workspace helps you a great vscode webview with Angular.

This article is deeply inspired by nx console where most of the concepts come from. The code below is available in this repository.

Create the workspace

Create an nx workspace. Let’s keep it empty for now and use the angular CLI.

npx create-nx-workspace studio
-> What to create in the new workspace: empty
-> CLI to power the Nx workspace      : Angular CLI

cd studio/

Create vscode extension application

Scaffold the app

vscode extension are node programs that run inside the ide.

We’ll need @nrwl/node schematics for that :

npm i -D @nrwl/node
ng generate @nrwl/node:application vs-code

Setup vscode

This application is the empty point for your extension and requires the vsode api :

npm i vscode

Now let’s update the main.ts file inside our app :

import { commands, ExtensionContext, window } from 'vscode';

// On activation
export function activate(context: ExtensionContext) {
  // Register command "start"
  commands.registerCommand('start', () => {
    window.showInformationMessage('Hello World');
  })
}

This code associates a callback that shows “Hello World” with the command “start”, when the extension in activated. Now we need to :

  • Create the command.
  • Activate the extension when the command is triggered.

For that vscode needs a package.json. Let’s add it in the same folder as main.ts :

{
  "name": "studio",
  "version": "0.0.0",
  "main": "main.js",
  "engines": {
    "vscode": "^1.44.0"
  },
  "contributes": {
    "commands": [{
      "command": "start",
      "title": "Start My Extension"
    }]
  },
  "activationEvents": [
    "onCommand:start"
  ]
}

Let’s keep it to the bare minimum for now:

  • contributes: This is where we create the command “start”
  • activationEvents: This will activate the extension when command “start” is triggered.

Build the extension

When running ng build vs-code it will only outputs the main.js files, not the package.json.

To solve that let’s update angular.json Under projects/vs-code/architect/build/options/assets add the path to package.json:

"assets": [
  "apps/vs-code/src/assets",
  "apps/vs-code/src/package.json"
]

Run ng build vs-code again. Everything is ready !

Setup launch.json & tasks.json

To run a vscode extension in development mode you need to create launch.json & tasks.json inside the folder .vscode.

I just pasted the code from the yo generator for vscode extension & change the extensionDevelopmentPath argument :

launch.json

{
  "version": "0.2.0",
  "configurations": [
    {
      "name": "Run Extension In Dev Mode",
      "type": "extensionHost",
      "request": "launch",
      "runtimeExecutable": "${execPath}",
      "args": [
        "--extensionDevelopmentPath=${workspaceFolder}/dist/apps/vs-code"
      ],
      "trace": "false",
      "internalConsoleOptions": "openOnFirstSessionStart",
      "outFiles": [
        "${workspaceFolder}/dist/apps/vs-code"
      ],
      "preLaunchTask": "${defaultBuildTask}"
    }
  ]
}

tasks.json

{
  "version": "2.0.0",
  "tasks": [
    {
      "type": "npm",
      "script": "watch",
      "problemMatcher": "$tsc-watch",
      "isBackground": true,
      "presentation": {
        "reveal": "never"
      },
      "group": {
        "kind": "build",
        "isDefault": true
      }
    }
  ]
}

I’m pretty sure there is a bunch of improvement to do here. But it worked in my case so I didn’t looked too much into details.

Try it out

First build you node app :

ng build vs-code --watch

Then press F5. It should open a new vscode window. For there hit Ctrl+p and write :

> Start My Extension

If everything goes well, you should see a message “Hello World” 🎉.

“Start My Extension” is the value we gave on the command “start” in the package.json.

Create a Webview with Angular

vscode extensions are powerful but the exposed API is quite limited when it comes to user interaction. Fortunately the API can run HTML code inside a webview. Let’s update the main.ts :

import { commands, ExtensionContext, window, ViewColumn } from 'vscode';

// On activation
export function activate(context: ExtensionContext) {
  // Register command "start"
  commands.registerCommand('start', () => {
    const panel = window.createWebviewPanel(
      'studio', // Key used to reference the panel
      'Studio', // Title display in the tab
      ViewColumn.Active, // Editor column to show the new webview panel in.
      { enableScripts: true });

    panel.webview.html = '<h1>Hello World</h1>';

    context.subscriptions.push(panel);
  })
}

If you didn’t stop your debugger you just need to click Restart (Ctrl+Shift+F5). And play “Start My Extension”.

Now you should see “Hello World” in a new tab 🎉.

This is a good start, but as you can imagine it’s going to be a pain to build a decent UX with a single html string. Let’s see how we can connect an Angular application instead.

Create Angular Application

Create the application

npm i -D @nrwl/angular
ng generate @nrwl/angular:application studio

The first thing to do it update the outputPath of the angular application to put it inside the dist folder of the vs-code extension:

In angular.json change projects/studio/architect/build/options/outputPath to :

"outputPath": "dist/apps/vs-code/studio"

Also, because your app is not served by a server you need to useHash for your router :

RouterModule.forRoot([], { useHash: true })

run ng build studio. The application will be outputed inside the vs-code project.

Run angular inside webview

Now we would like to do something like that :

import { promises as fs } from 'fs'; // Require @types/node@latest
import { join } from 'path';

// On activation
export function activate(context: ExtensionContext) {
  // Register command "start"
  commands.registerCommand('start', async () => {
    ...
    const indexPath = join(context.extensionPath, 'studio/index.html');
    const html = await fs.readFile(indexPath, 'utf-8');
    panel.webview.html = html;
    ...
  })
}

But webview required special vscode URI to load local content. For that we need to transform all src & href into an URI. We can achieve that with a regex :

const html = await fs.readFile(join(context.extensionPath, 'studio/index.html'), 'utf-8');

// 1. Get all link prefixed by href or src
const matchLinks = /(href|src)="([^"]*)"/g;
// 2. Transform the result of the regex into a vscode's URI format
const toUri = (_, prefix: 'href' | 'src', link: string) => {
  // For <base href="#" />
  if (link === '#') {
    return `${prefix}="${link}"`;
  }
  // For scripts & links
  const path = join(context.extensionPath, 'studio', link);
  const uri = Uri.file(path);
  return `${prefix}="${panel.webview['asWebviewUri'](uri)}"`;
};
// 3. Replace the all link from the index.html into a URI format
panel.webview.html = html.replace(matchLinks, toUri);

Ok, if like me you’re not a regex wizard, let’s take a closer look :

  1. This regex will capture all links prefixed by either “href” or “src” in the built index.html.
  2. We transform the result of the match into a URI based that point to right directory.
  3. We replace all links with the right URI.

At the time of writing (May 2020) the asWebviewUri isn’t available in the types of “webview” but is in the doc & works.

Here is the full code :

import { commands, ExtensionContext, window, ViewColumn, Uri } from 'vscode';
import { promises as fs } from 'fs';
import { join } from 'path';

// On activation
export function activate(context: ExtensionContext) {
  // Register command "start"
  commands.registerCommand('start', async () => {
    const panel = window.createWebviewPanel(
      'studio',
      'Studio',
      ViewColumn.Active,
      {
        enableScripts: true,
        localResourceRoots: [Uri.file(join(context.extensionPath, 'studio'))]
      });

    const html = await fs.readFile(join(context.extensionPath, 'studio/index.html'), 'utf-8');

    const matchLinks = /(href|src)="([^"]*)"/g;
    const toUri = (_, prefix: 'href' | 'src', link: string) => {
      // For <base href="#" />
      if (link === '#') {
        return `${prefix}="${link}"`;
      }
      // For scripts & links
      const path = join(context.extensionPath, 'studio', link);
      const uri = Uri.file(path);
      return `${prefix}="${panel.webview['asWebviewUri'](uri)}"`;
    };

    panel.webview.html = html.replace(matchLinks, toUri);

    context.subscriptions.push(panel);
  })
}

The snippet above adds localResourceRoots in the options to make sure we can only load local content from this directory.

Build and test

Let’s run everything.

ng build studio --prod
ng build vs-code

Then press “F5” to open a new window and inside :

  • Press Ctrl+P
  • Write “Start Extension”

Now your angular application should open on a new tab 🚀

Watch

Our application is running in a webview but if we change something inside it doesn’t update the webview.

Listen on changes

The idea is to listen on file changes, and reassign the webview.html. In main.ts let’s add a listener in development mode :

const index = join(context.extensionPath, 'studio/index.html');

// Refresh the webview on update from the code
const updateWebview = async () => {
  const html = await fs.readFile(index, 'utf-8');
  panel.webview.html = html.replace(matchLinks, toUri);
}

// In dev mode listen on changes from index.html & update the view
if (!environment.production) {
  watch(index).on('change', updateWebview)
}
// First render
updateWebview();

For this to work we need to enable outputHashing in development mode for our angular app. In angular.json update projects/studio/architect/build/options/outputHashing to “all”

"outputHashing": "all"

Each time a change occurs in the code, every chunk depending on this change will be triggered will have a new hash. index.html beeing the root we should catch all changes.

Build and watch

Now we need to build our extension & angular application in watch mode in two terminals :

ng build studio --watch
ng build vs-code --watch

Press “F5”, run the command and change your code to see the refresh.

Hot Module Reload

I didn’t implemented yet, but a little bit of code we should be able to create a Hot Module Reload by keeping the state in the extension. It’s actually recommended to keep the application stateless and pass set the state on vscode with setState & getState.

Conclusion

After a little bit of work we have everything needed to build our vscode extension with a webview. Now you can shre your libraries with the extension & webview.

Limitations

The main limitation I found was the inability to use lazy loaded modules. I think it’s because of the vscode URI requirement, but it might comes from somewhere else…

Thanks

Special thanks to the Nrwl team for building nx workspace & nx console. Please take a look at the nx console repository for more advanced settings (test, ci, …). Also many thanks to Bruce Delorme for his help with the Regular Expression.
